Basic Use of the Exergen Consumer TAT-2000/TAT-2000C – Best Temporal Artery Thermometer TAT-2000/TAT-2000C

Accurate Temperature with a Gentle Forehead Scan – The Best Temporal Thermometer
#1 Bestselling Thermometer Brand. The TemporalScanner Thermometer is a totally non-invasive system with advanced infrared technology providing maximum ease of use with quick, consistently accurate measurements. Advanced, patented technology measures temperatures with a gentle stroke across the forehead. It captures naturally emitted heat from the skin above the temporal artery, 1,000 times a second and then gives a reading of the most accurate temperature.

• Fast, Easy and Accurate
• Accurate Temperature With a Gentle Forehead Scan
• Preferred by Nurses and Pediatricians
• Soft Glow Display and 8 Temperature Memory

Breakthrough Technology

TemporalScanner™ Temporal Artery Thermometry

With just a light stroke across the temporal artery area of the forehead, an accurate reproducible temperature is measured in about 3 seconds – eliminating any discomfort caused by a thermometer inserted into the ear, mouth, or rectum. Designed specifically to be completely non-invasive, the TemporalScanner is a most significant advance, applying Exergen’s well-proven Arterial Heat Balance (AHB) technology to the most convenient site possible.

Branching from the external carotid, the superficial temporal artery courses about 1 mm below the skin of the lateral forehead, providing good heat conduction to the skin surface. The TA is readily accessible, and provides no risk of injury from being touched. Since it is not an anastomosing vessel, perfusion remains high and stable, ensuring the reliability of conditions for the patented AHB method to compute accurate temperatures. High resolution infrared images confirm the reliability of the heat signature of the TA area for all ages.

Arterial Heat Balance (AHB) at the Temporal Artery at Room Temperature

Blood at Ta Is supplied to the temporal artery from the aorta via the carotids, and is cooled by heat energy lost to the environment at te resulting in cooler Tta, By measuring this heat loss and adding it back to Tta the AHB is formed and Ta is then recovered.

Testimonials

“We have found the TA thermometer to be significantly more accurate than the tympanic thermometer. This is in predicting rectal temperature in infants. The TA thermometer is significantly more sensitive than the tympanic thermometer. Especially for the detection of rectal fever in infants. The TA thermometer is better tolerated by patients than the rectal thermometer.”

Specification

Clinical accuracy

EMI/RFI Protection
Calibration Protection
Temperature Range
Operating Environment
Resolution
Response Time
Time Displayed on Screen
Battery Life
Size
Weight
Display Type
Construction Method
Warranty
Patents

Meets ASTM E 1965-98 and EN60601-1 standards for electronic and radiation thermometers to the extent applicable to thermometers which measure the surface of the skin over the temporal artery.
Error message displayed
Error message displayed
15.5 to 42°C (60 to 107.6°F)
15.5 to 40°C (60 to 104°F)
0.1°C or °F
Approximately 0.03 second
30 seconds before automatic shutdown
Approximately 7,500 readings
7.0 in x 1.75 in x 1.25 in (17.8 cm x 4.45cm x 3.18 cm)
4.2 oz (120 grams) incl batt
High contrast LCD’s
Impact resistant casing, hermetically sealed sensing system
2 years
Listed at www.exergen.com/patents

ASTM laboratory accuracy requirements in the display range of 37° to 39°C (98 to 102°F) for IR thermometers is +/-0.2°C (+/- 0.4°F) whereas for mercuryin-glass and electronic thermometers, the requirement per ASTM standards E667-86 and E1112 is +/-0.1°C (+/-0.2°F).

*Full responsibility for this product meeting applicable portions of this
standard is assumed by Exergen Corporation, Watertown, MA 02472

Ensuring superior functionality in the most demanding of hospital environments, the TAT-5000 series easily stands up to the heavy duty demands of a high-performance hospital workplace, including intensive care units and emergency departments, and all inpatient units. Depending on patient care requirements, this model allows the choice of using disposable covers, or cleaning between patients with a disinfectant wipe, providing the means for significant cost savings by eliminating or substantially reducing probe cover usage. This revolutionary feature provides payback for full hospital installation in less than one year.

Breakthrough Technology

TemporalScanner™ Temporal Artery Thermometry

With just a light stroke across the temporal artery area of the forehead, an accurate reproducible temperature is measured in about 3 seconds – eliminating any discomfort caused by a thermometer inserted into the ear, mouth, or rectum. Designed specifically to be completely non-invasive, the TemporalScanner is a most significant advance, applying Exergen’s well-proven Arterial Heat Balance (AHB) technology to the most convenient site possible.

Branching from the external carotid, the superficial temporal artery courses about 1 mm below the skin of the lateral forehead, providing good heat conduction to the skin surface. The TA is readily accessible, and provides no risk of injury from being touched. Since it is not an anastomosing vessel, perfusion remains high and stable, ensuring the reliability of conditions for the patented AHB method to compute accurate temperatures. High resolution infrared images confirm the reliability of the heat signature of the TA area for all ages.

Arterial Heat Balance (AHB) at the Temporal Artery at Room Temperature

Blood at Ta Is supplied to the temporal artery from the aorta via the carotids, and is cooled by heat energy lost to the environment at te resulting in cooler Tta, By measuring this heat loss and adding it back to Tta the AHB is formed and Ta is then recovered.

Exergen TAT-5000S Connected Models are now available on leading Vital Signs Monitors for EHR Data Integration

Philips SureSigns VS4

Midmark IQvitals® Zone

Spacelabs Qube®, Xprezzon®, Qube® Mini

GE Healthcare VC150, V100, Corometrics

Capsule SmartLinx Vitals Plus

ZOE 740Select

Schiller Diagnostic Station DS20

Testimonials

“We have found the TA thermometer to be significantly more accurate than the tympanic thermometer. This is in predicting rectal temperature in infants. The TA thermometer is significantly more sensitive than the tympanic thermometer. Especially for the detection of rectal fever in infants. The TA thermometer is better tolerated by patients than the rectal thermometer.”

• Fast, safe, and comfortable for the patient
• Fast, easy, and convenient for the clinician
• Low cost system: payback less than 1 year
• Disposable cover use optional
• Industrial-duty construction: Lifetime Warranty
• CD-ROM training disk included

High Accuracy

Non-Contact Measurement

With bothering the baby and they feel no discomfort, the thermometer with high-end sensors is of high accuracy to detect and read the temperature within 1 second, with ±0.2℃ Tolerance.

There is an Easier Way to Measure Temperature.

Day or night, adult or baby, or even a pet dog, it is the perfect and quickest way to measure our families temperature, with no fess.

99.8% Pass Rate
Manufacturing is Taken Seriously at Berrcom.

We are sure to promise that your business with Berrcom is a smart choice. A good product comes from not only design but also manufacturing.

We select raw material from reliable suppliers to produce all parts and components for making a thermo.

With Quality Controlling system, we are confident to present you the perfect products.
